12″ x 3″ Kingpinless, (PH) Phenolic Wheel

57/58 Heavy Duty Kingpinless Yokes – Rated up to 7,000 lbs.

• ASTM1045 drop forged swivel head, 5/16” thick, 3” diameter precisely machined and hardened raceway, loaded ½” dia. hardened ball bearings
• Viton® Seal integrated with raceways available
• Legs are double welded 3/8” thick steel
• Grease fitting on raceway and axle
• 3/4” axle bolt/nut
• Zinc plated finish

(PH) PHENOLIC

• Canvas fiber filled Phenolic for high impact resistance
• Temperature range : -50° F to +250° F
• Durometer: Shore D 90(+/-5)
